Technical Information
First Stage
- Air-balanced flow-through piston in a chrome plated brass body provides constant and effortless airflow unaffected by depth, tank pressure, or breathing rate.
- Patented XTIS (Extended thermal Insulating system) thermally insulates the inner mechanism from the environment, improving cold-water resistance by 30% and delaying ice formation in extreme cold-water conditions without compromising breathing performance. Key insulation system components are visible in blue.
- Anti-freeze protection radically increases breathing reliability when diving in the most extreme water temperatures.
- Two opposing high pressure ports allow the first stage to be positioned either up or down.
- Four high-flow and one axial super high-flow low pressure ports on a swivel turret maximize hose routing options.
- External intermediate pressure adjustment enables technicians to fine-tune performance quickly and easily.
- Available in a 3364psi/232 bar INT configuration.
- Airflow at 2900psi/200bar: (l/min/SCFM): >8500/301.
- Intermediate pressure (psi/bar): 133-142/9.2-9.8.
- Weight: INT 232 (oz/g): 27.9/790.
Second Stage
- Air-balanced valve smoothes out the inhalation effort at varying depths and supply pressures.
- Rugged reinforced technopolymer case and front cover with stainless steel frame looks good plus is able to withstand years of aggressive diving.
- Titanium barrel is rugged, anti-corrosion and lightweight for long-term reliability.
- Large diaphragm fits inside a more compact casing for maximum breathing sensitivity.
- User controls include an easy-grip diver-adjustable inhalation effort knob and Venturi-Initiated Vacuum Assist (VIVA) lever.
- New exhaust tee increases performance while directing bubbles out of the field of view.
- Newly designed Compact Hi-Flow mouthpiece, exclusive to the S620 Ti, is mounted on an enlarged mouthpiece pipe to improve airflow as well as mouth comfort.
- Super-flow hose features an oversized bore that allows more air to flow on each inhalation.
- Specific matching colors (blue, pink, yellow, purple, white and orange) on mouthpiece and hose protector are available as an accessory.
- Weight (without mouthpiece): 6.3oz/179g.
- Airflow at 2900psi/200bar: 1850 l/min – 66 SCFM.
